Additive manufacturing · Malaysia

Precision parts, printed to spec — and objects worth keeping.

Two machines, two disciplines. An engineering-grade line producing high-precision components for industry, and a commercial line making ready-to-order pieces and premium custom work.

Request a quote Shop ready-made

Resin · Nylon · Engineering thermoplasticsMaterial range

Semiconductor · Electronics · AutomationIndustries served

STL · STEP · 3MF · 2D drawingsFiles we quote from

Quoted per partNo list-price guesswork

Two ways to work with us

One workshop, two very different customers.

An engineering team buying functional parts and a customer buying a finished object need different conversations. We keep them separate from the first click.

B2B · Engineering

Parts that have to work

Jigs, fixtures, housings, end-effectors, prototype assemblies and low-volume production parts — printed in resin, nylon or engineering thermoplastics, quoted against your drawing.

See capabilities Send an RFQ

B2C · Ready-made & custom

Objects you can order today

Desk pieces, planters, lighting and decor from our commercial line — or a custom piece made to your idea, in small runs for corporate gifting.

Browse the range Ask about custom

Capabilities

Three processes, chosen by what the part has to survive.

We match the process to the job rather than pushing whichever machine is free. If a part is better machined than printed, we say so.

SLA · Resin

Detail and finish

Fine-feature prototypes, enclosures, jigs and visual models where surface quality and small detail matter more than impact strength.

Standard and tough/ABS-like resins
High-temperature and flexible resins
Clear and water-resistant options
Best surface finish of the three

SLS / MJF · Nylon

Functional strength

End-use brackets, ducting, fixtures and living-hinge parts that need to take load, heat and repeated handling without support structures.

PA12 nylon, unfilled and glass-filled
No support marks on mating faces
Small-batch production runs
Dyeing, bead blasting, tumbling

FDM · Thermoplastic

Size and toughness

Large formwork, guards, tooling aids and shop-floor parts where build volume, cost per gram and impact resistance decide the choice.

PLA, PETG, ABS, ASA, TPU
Carbon-fibre nylon and PC
Largest build envelope
Threaded inserts and assembly

Materials we work in

Common market materials, selected per application. Anything outside this list, ask — we will tell you if it is the right call.

Material	Process	Typical use	Watch out for
Standard resin	SLA	Prototypes, enclosures, models	Brittle under impact; not for load
Tough / ABS-like resin	SLA	Snap fits, jigs, handles	Better impact, still UV-sensitive
High-temp resin	SLA	Moulds, hot-air fixtures	Limited flex; check continuous heat
PA12 nylon	SLS / MJF	Brackets, hinges, end-use parts	Porous surface unless sealed
Glass-filled PA12	SLS / MJF	Stiffer structural parts	More abrasive, less elongation
PETG / ASA	FDM	Guards, covers, outdoor parts	Layer lines; anisotropy under load
TPU	FDM	Gaskets, grips, dampers	Slow to print; limited detail
PA-CF (carbon nylon)	FDM	Tooling, stiff functional parts	Requires hardened nozzle; brittle in thin walls

Post-processing

Finished, not just printed

Support removal and cleaning
Sanding, filling, primer and paint
Bead blasting and vapour smoothing
Dyeing to colour
Threaded inserts, tapping, assembly

Inspection

Checked before it ships

Dimensional check against drawing
First-article report on request
Photos of the finished part before dispatch
Material batch recorded per job

Commercial

How we quote

Priced per part, per material, per quantity
No list price published for engineering work
Lead time confirmed with the quote
Repeat orders keep the same process and finish

Who we print for

Industries where a printed part has to earn its place.

SemiconductorFixtures, wafer-handling aids, cleanroom jigs and ESD-conscious tooling where geometry and repeatability matter.

Electronics manufacturingTest fixtures, connector housings, cable management and line-side tooling that has to fit the first time.

Automation & engineeringGrippers, end-effectors, sensor mounts and guards — low mass, complex geometry, short lead time.

Injection moulding & toolingPrototype inserts, gauges, check fixtures and mould-side aids for proving a design before steel is cut.

AutomotiveBrackets, ducting, jigs and interior prototype parts for validation builds and assembly lines.

Product & industrial designAppearance models, working prototypes and short-run production for teams moving faster than a tool can be cut.

B2B showcase

Work coming off the engineering line.

Representative parts from recent jobs. Specs shown are what the part was printed to — not a catalogue of what the machine can theoretically do.

SLA · Tough resin

Assembly jig with nesting pockets

Holds a connector body at a fixed angle during soldering. Printed with locating pins and a relief channel for the cable.

Quantity: 12 per line
Finish: Sanded, matte clear

SLS · PA12

Robotic end-effector fingers

Low-mass gripper fingers with internal lattice, replacing machined aluminium on a pick-and-place cell.

Quantity: 40 sets
Finish: Bead blasted

SLA · Standard resin

Enclosure prototype set

Five-part electronics enclosure with snap fits and a light pipe, used for fit checks before tooling release.

Quantity: 3 sets
Finish: Primer, painted

FDM · PA-CF

Carbon nylon tooling aid

Drill guide for a repeat assembly operation, with hardened insert bushes pressed in after printing.

Quantity: 6
Finish: As printed, inserts fitted

MJF · Glass-filled PA12

Conveyor guide rail section

Wear part for a packaging line, printed in glass-filled nylon to hold stiffness across a long span.

Quantity: 24
Finish: Tumbled

FDM · ASA

Machine guard and duct adaptor

Outdoor-rated guard section with an integrated duct adaptor, printed in one piece to remove a weld step.

Quantity: 8
Finish: Sanded, UV-stable

Shop & custom

Ready to order, or made to your idea.

Our commercial line handles small, finished objects — for desks, homes, gifts and corporate orders. Prices shown are indicative retail for this demonstration; custom work is quoted per piece.

Modular desk dock

Stacking tray for pens, cards and a phone, in matte charcoal.

RM 89 incl. delivery

Faceted planter, 12 cm

Watertight liner with a drainage insert. Four colourways.

RM 65 incl. delivery

Ribbed lamp shade

Printed in translucent resin, warm diffused light, E27 fitting.

RM 149 incl. delivery

Headphone stand

Weighted base, cable channel down the spine.

RM 79 incl. delivery

Corporate award piece

Made to order in small runs, engraved plate, your choice of finish.

From RM 180 quoted per piece

Custom order

Have something in mind?

Send a sketch, a reference photo or a rough dimension and we will come back with a price and a lead time. One-off pieces and small runs both welcome.

Start a custom order

Retail prices shown are indicative for this demonstration site. Engineering parts are quoted per part and per quantity.

How it works

From file to finished part.

Send the filesSTEP or STL for geometry, a 2D drawing if there are tolerances, and a note on what the part has to do.

We review itWe check wall thickness, orientation and material fit, then quote per part with a lead time.

Print and finishChosen process, agreed finish, and a photo before dispatch.

Inspect and packDimensional check against the drawing, packed for transport.

Deliver and repeatCourier nationwide. Repeat orders keep the same process and finish.

Get a quote

Tell us about the part, or the piece you want made.

Every enquiry reaches a person, not a queue. Attach a drawing or model if you have one — it makes the quote faster and more accurate.

What helps us quote quickly

Geometry — STEP, STL, 3MF, OBJ or a PDF drawing, up to 25 MB.
Function — load, heat, chemical contact, or purely cosmetic.
Quantity — one-off, or a run you might repeat.
Deadline — the date you actually need it, not the ideal one.

Your files stay confidential and are used only to quote and produce your part.

Company

Industry

Your name *

Email *

Phone / WhatsApp

Quantity

Process interest

Target date

Part description *

Attach a file (optional, max 25 MB) Drop a CAD file or drawing here, or click to choose — STEP, STL, 3MF, OBJ, PDF, ZIP

By sending this you agree we may contact you about this enquiry. We do not add you to a mailing list.

Questions

The things people ask before the first order.

What files should I send?

STEP is best for engineering parts because it carries real geometry. STL works but loses units and curves. Add a 2D drawing as PDF if there are tolerances or critical features. For consumer pieces a photo or sketch is enough to start.

How is the price worked out?

Per part: material volume, machine time, post-processing and quantity. Engineering parts are quoted per job — we don't publish a list price because two parts the same size can differ tenfold in print time and finishing.

How long does it take?

Confirmed with your quote. Small resin parts are usually days, not weeks. Large FDM parts and finishing work take longer. If you have a hard date, say it up front and we will tell you honestly whether we can hold it.

Can you match a specific tolerance?

We will tell you what the chosen process can hold for your geometry, and where it cannot. If a feature needs machining to hit the number, we will say that rather than print it and hope.

Is my design safe with you?

Files are used only to quote and produce your part. We don't resell, publish or reuse customer geometry. If you need an NDA before sending files, ask and we will sign one first.

Do you do small production runs?

Yes — tens to low hundreds depending on the part and process. Above that, injection moulding usually wins on unit cost and we will tell you when you have crossed that line.
